Öl & Gas Zum Verkauf

EQUIPMENT-FROM-LEGACY-UNDERGROUND-CONSTRUCTION

EQUIPMENT-FROM-LEGACY-UNDERGROUND-CONSTRUCTION

Water Damaged

Air Ride Suspension • Air Brakes • Aluminum Wheels • 275/70R22.5 Tires • 90718 lb GVWR • Per Seller: 2019 Premier Coiled Tubing Rig Package Includes: *2020 Kenworth 12x6 Heavy Haul T/A Day Cab Truck Tractor* 2-3/8" Reel Trailer 24 •000ft Capacity w/PCS-130 Injector Head • Control Cabin * One-Piece Support Trailer w/Power Pack • Fuel Tank • Riser Skid • Hydraulic BOP Tilt Frame * Tridem Jeep * Tridem Booster *Lubricators (Located in E Texas)* Spare Reel & (2) Frames (Located in Midland • TX) 1NKDX4TX8LR373279 Kenworth Truck Tractor 7KF1P7268KA000109 Mertz Coil Tubing Trailer 5JYDF5331KED13362 Dorsey Support Trailer 7KF1P3637KA000045 Mertz Jeep Trailer 7KF1P1222KA000049 Mertz Booster Trailer

12 ft L x 12 ft W Substructure • Stairs • Safety Rails • Schramm Drawworks • 325 kW Generator • 250 kW Generator • Schaffer/Townsend 9 in 21000 psi Blowout Preventer • Triplex Pump • (1) Shale Shakers***Please see the specification documents below.***

- Engine: Hyundai; Power - 420PS/2000RPM; Cooling System - Water Cooling; - Drill Head Section: Reduction - Super gear - 5.1 to 1; Max. RPM - 1st 0-150rpm; 2nd 0-200rpm; Max. Torque - 1st 2600kg-M; 2nd 1300kg-M; - Feed System Head travel 1st: 11M; 2nd: Up- 1.4M • Down- 1.8M Pull-up capacity 120ton Pull-down capacity 9ton - Main Feed Winch Spool capacity 30M of 19㎜ cable Line pull 17 tons - Sub Feed Winch Spool capacity 25M of 16㎜ cable Line pull 9 tons - Winch Spool capacity 27M of 12㎜ cable Line pull 3 tons - Main Hydraulic System 3 pump open loop system Pump discharge rate H3V280DT (P1:280cc • P2:280cc) +Gear Pump(P3:10cc) - Sub Hydraulic System 4 pump open loop system - Pump discharge rate H3V63DT (P1:63cc • P2:63cc) +HSF30D (P3:30cc • P4:30cc) - Working Table Max. Casing diameter 12" Lod Handler Tilting Degree 90° Lod Handler Clamp Size Max 127mm - Crawler Base Crawler type Solar 220 (Motor : Solar 220) Ground pressure 0.5㎏/㎠

1.7 MMBTU/hr • 6100psi • 4M Length • Coil Diameter 20 inch •

Uniflux heater with low NOx natural gas burner • heat transfercoil • seespec sheet • See Attached Spec Sheet in listing

3 in Standpipe & Manifold • Hydraulic-Explorer 2 3000 496 kW Drawworks • Marathon MagnaMax 305 kW Generator • Control Technology 9 in 21000 psi Blowout Preventer • Triplex Pump • (1) Shale Shakers • Foremost Pipe Arm Catwalk • Rig Moves Quickly • Small Footprint • Capable of Operating Independently Without the Need for a Third Party Coring Unit

Compressor • E-motor • Oil Separator • Gas After Filter • Oil Pumps • E-motor for Oil Pumps • Oil Cooler • Oil Filters • Seal Oil Drain Tank • Seal Oil Buffer Tanks • Piping & Valves • Junction Boxes • and Instrumentation.

Out and Down Outriggers • Rear Outriggers • detroit series 60 6 Cylinder 12.7 L Diesel 500 hp Engine • 2002 US EPA Label • Positive Air Shutoff • 14188 Engine hrs • Allison 5-Speed Automatic Transmission • Differential Lock • Aluminum Wheels • 425/65R22.5 Front Tires • 12R22.5 Rear Tires • Air Assist Front Suspension • Rubber over Walking Beam Suspension • 292 in Wheelbase • Hydraulic System • kremco 2 Drum Drawworks • LEBUS Grooved • 72 ft stiff mast • 38X10 Draw Works • BOP Class II 7 in 3K • Mast hours 4977 • BOP Tubing • Tongs and Basket for Crane

Cat C15 6 Cylinder Upper Engine • Straight Down Outriggers • Cat C15 6 Cylinder Diesel 540 hp Engine • Positive Air Shutoff • 37855 Engine hrs • Automatic Transmission • Aluminum Outer Wheels • 425/65R22.5 Front Tires • 11R24.5 Rear Tires • Dual Steering Boxes • Walking Beam Suspension • 294 in Wheelbase • PTO • Hydraulic System • Eagle 2 Drum Drawworks

Winch • Out and Down Outriggers • Rear Outriggers • Onan Diesel Generator Set • Paccar PX-8 6 Cylinder 8.3 L Diesel 330 hp Engine • 614 Engine hrs • Air Conditioner • Cruise Control • Engine Brake • Eaton Fuller FRO11210C 10-Speed Manual Transmission • 12000 lb Front Axle • 40000 lb Rears • Spicer DSP41P Drive Axles • 4.88:1 Axle Ratio • 52000 lb GVWR • 275/80R22.5 Front Tires • 295/75R22.5 Rear Tires • Hendrickson Air Ride Suspension • 248 in Wheelbase • Dual PTO • 1 Drum Drawworks • Wireline Truck Fab Driller's Control Console

Detroit Diesel S60 Engine • Water Tank • Detroit S60 6 Cylinder Diesel Engine

4ft 11in. to 8ft 2in. • 486 tons of extracting force.

Detroit 12 Cylinder Diesel Engine • cotta Transmission • Open Top Control Station • T/A Carrier • Air Ride

Detroit 12 Cylinder Diesel Engine • Telescoping Cabin • T/A Carrier • Air Ride

Paccar PX-9 6 Cylinder 8.9 L Diesel 350 hp Engine • 2013 US EPA Label • Requires Diesel Exhaust Fluid • Positive Air Shutoff • Webasto Engine Coolant Heater • 2957.9 Engine hrs • Air Conditioner • Cruise Control • Power Windows • Engine Brake • Allison 3000 Automatic Transmission • Differential Lock • 6623 kg Front Axle • 10433 kg Rears • Dana S23-170 Drive Axles • 5.25:1 Axle Ratio • 17055 kg GVWR • Aluminum Wheels • 12R22.5 Front Tires • 11R22.5 Rear Tires • Hendrickson Air Ride Suspension • 238 in Wheelbase • PTO • 23 ft x 102 in Bed • Winch • Pintle Hitch • C-Tech Model X-300 Injector • Hyd Scope Bed • Rear Hyd Outriggers • Fassi Micro M30A 13 Picker • Passenger Side Hyd Extend Racks

600 HP HPU • 5 •000 psi rated system • 130 gpm plumbed to 2 of 3 rails • variable displacement Parker pumps • 1500 gal. reservoir • PLC controlled • 480V 3 phase primary power • VFD motor control • outdoor rated • skid mounted • remote oil cooler • pump and motor group can be added to third rail for future expansion.

Cat C15 15.2 L Diesel 500 hp Engine • 2005 US EPA Label • Positive Air Shutoff • 1820.5 Engine hrs • Air Conditioner • Cruise Control • Power Windows • Engine Brake • Eaton Fuller 18-Speed Manual Transmission • Triple Differential Locks • Air Ride Cab • Aluminum Wheels • 425/65R22.5 Front Tires • 11R24.5 Rear Tires • Dual Steering Boxes • Double Frame • Airliner Air Ride Suspension • 302 in Wheelbase • PTO • Dual Fuel Tanks
